Samsung Galaxy Note10 (SM-N970F) Schematic

Samsung Galaxy Note10 (SM-N970F) Schematic files free download

Galaxy Note10 model SM-N970F. Known for its powerful performance and sleek design, it’s a popular choice among users.

Key Features of the Galaxy Note10:

• Processor: Exynos 9825 / Qualcomm Snapdragon 855
• Graphics: Mali-G76 MP12 / Adreno 640
• Display: 6.3-inch Dynamic AMOLED, 1080 x 2280 pixels
• RAM: 8GB
• Storage: 256GB, non-expandable
• Camera: Triple rear (12MP + 12MP + 16MP), 10MP front camera
• Battery: 3500mAh with fast charging
• Operating System: Android 9.0 (Pie), upgradable

Why Wait?

Grab the schematic, fire up your soldering iron, and turn that “dead” board into a victory. Tech repair is 10% mystery, 90% having the right map. 🔍

Open the .CAD file with OpenBoardView or Altium 365.

Open the PDF file whith Acrobat Reader

Legal Disclaimer

Manufacturer does not publicly release schematics or boardview files. These resources are shared to aid responsible repair efforts. Always comply with local laws and avoid unauthorized distribution. The information provided here is based on available specifications and features at the time of writing. Always check the official product documentation for the most up-to-date details. Use these schematics at your own risk.
