MSI GF63 (MS-16R3) (MS-16R31) Boardview

MSI GF63 (MS-16R3) (MS-16R31) Boardview files free download

Laptop MSI GF63 Features:

1. Powerful Performance:

   • The laptop is powered by up to a 10th Gen Intel® Core™ i7 processor (Comet Lake H) for excellent gaming performance.
   • With up to 6 cores and a maximum turbo frequency of 5.0 GHz, it delivers impressive processing power.
   • The higher core frequency contributes to an enhanced gaming experience.

2. NVIDIA Max-Q Graphics:

   • The GF63 Thin features NVIDIA Max-Q, an innovative approach to thin and quiet gaming laptops.
   • It strikes a balance between excellent GeForce gaming performance and an incredibly elegant design.
   • The laptop is available with different graphics options, including the GeForce GTX 1650 Ti Max-Q, GTX 1650 Max-Q, and GTX 1050 Ti Max-Q.

3. Cool and Quiet Under Load:

   • Designed to remain cool and quiet even during intense gaming sessions.
   • It’s up to 10% quieter and 10% cooler compared to previous models.
   • The combination of efficient cooling and quiet operation ensures a comfortable gaming experience.

4. 144Hz IPS Display with Slim Bezels:

   • The laptop features a 15.6-inch Full HD display with a 144Hz refresh rate.
   • The slim bezels provide an immersive viewing experience, allowing you to focus on the game.
   • Optional IPS technology ensures vibrant colors and wide viewing angles.

5. Sleek and Lightweight Design:

   • The GF63 Thin boasts an aluminum brushed finish on the lid and keyboard area.
   • The X-shaped hidden ventilation adds a touch of style.
   • It weighs just 1.86 kg and has a thickness of 21.7 mm, making it highly portable.

Boardview

Open the .CAD file with OpenBoardView or Altium 365.

Open the PDF file whith Acrobat Reader

Legal Disclaimer

Manufacturer does not publicly release schematics or boardview files. These resources are shared to aid responsible repair efforts. Always comply with local laws and avoid unauthorized distribution. The information provided here is based on available specifications and features at the time of writing. Always check the official product documentation for the most up-to-date details. Use these schematics at your own risk.
