COMPAL HAL00-LA-2792P BOARDVIEW

COMPAL HAL00-LA-2792P BOARDVIEW files free download

The Dell Latitude D620 with the COMPAL HAL00-LA2792P motherboard has several key features:

• Processor: Intel Core 2 Duo (Intel Core 2 Duo T7100, T7200, T7300, T7400, T7500, T7600)
• Graphics: Integrated Intel GMA 950 graphics
• Display: 14.1-inch WXGA (1280 x 800) TFT
• Memory: Supports up to 8GB DDR2 RAM
• Storage: Up to 320GB HDD
• Battery: Standard 6-cell, 56Wh Li-ion battery
• Operating System: Windows XP Professional, Windows Vista Business, Windows 7 Professional
• Connectivity: Wi-Fi 802.11a/b/g, Bluetooth 2.0, Ethernet port
• Ports: 3 x USB 2.0, 1 x VGA, 1 x RJ-45, 1 x headphone/microphone combo jack

Why Wait?

Grab the schematic, fire up your soldering iron, and turn that “dead” board into a victory. Tech repair is 10% mystery, 90% having the right map. 🔍

Open the .CAD file with OpenBoardView or Altium 365.

Open the PDF file whith Acrobat Reader

Legal Disclaimer

Manufacturer does not publicly release schematics or boardview files. These resources are shared to aid responsible repair efforts. Always comply with local laws and avoid unauthorized distribution. The information provided here is based on available specifications and features at the time of writing. Always check the official product documentation for the most up-to-date details. Use these schematics at your own risk.
