Motherboard Features: TA880GB (Rev 6.0)

The BIOSTAR TA880GB (Rev 6.0) is designed for AMD processors and offers robust performance. Its key features include:

• Supported Socket AM3 processors AMD Phenom II / Athlon II processor
• Supported AMD Mutil Core(x6,x4,x2)
• AMD 125W processor support
• AMD 880G Chipset with ATI Radeon HD 4250 DX10.1 Graphics
• 4 DIMM supported DDR3-1600(OC)/1333/1066
• ATI Hybrid Graphics Support
• Integrated HDMI/DVI interface with HDCP Support 1080P HD Video Experience
