- Version Rev 1.01
- Download 22
- File Size 297 Kb
- File Count 1
- Create Date 2025-06-09
- Last Updated 2025-06-09
ASUS ROG STRIX GTX 1050 Ti GAMING (CG210PI) (Rev 1.01) BOARDVIEW files free download
| Coprocesador de gráficos | NVIDIA GeForce GTX 1050 Ti |
| Marca | ASUS |
| Tamaño de la RAM de gráficos | 4 |
| Velocidad del reloj de GPU | 1379 MHz |
| Interfaz de salida de vídeo | HDMI, DVI, DisplayPort |
| Fabricante del procesador de gráficos | NVIDIA |
| Tipo de RAM de gráficos | GDDR5 |
Why Wait?
Grab the schematic, fire up your soldering iron, and turn that “dead” board into a victory. Tech repair is 10% mystery, 90% having the right map. 🔍
Open the .CAD file with OpenBoardView or Altium 365.
Open the PDF file whith Acrobat Reader
Legal Disclaimer
Manufacturer does not publicly release schematics or boardview files. These resources are shared to aid responsible repair efforts. Always comply with local laws and avoid unauthorized distribution. The information provided here is based on available specifications and features at the time of writing. Always check the official product documentation for the most up-to-date details. Use these schematics at your own risk.
