ASROCK B85M PRO4 (Rev 1.04) (70-MXGQ20-A11) BOARDVIEW

ASROCK B85M PRO4 (Rev 1.04) (70-MXGQ20-A11) BOARDVIEW files free download

The ASROCK B85M PRO4 combines stability with performance. Here’s what you need to know:

• Chipset: Intel® B85
• Memory: Dual-channel DDR3/DDR3L with a maximum capacity of 16GB
• Graphics: Intel® HD Graphics with support for Quick Sync Video, InTru™ 3D, and Clear Video HD Technology
• Audio: 7.1-channel HD audio with Realtek ALC892 Audio Codec
• LAN: PCIE x1 Gigabit LAN with Qualcomm® Atheros® AR8171

Motherboard Features: B85M PRO4

• A-Style : Home Cloud
• Supports New 4^th and 4^th Generation Intel^® Xeon^® / Core™ i7 / i5 / i3 / Pentium^® / Celeron^® Processors (Socket 1150)
• Supports Intel^® Small Business Advantage 2.0
• All Solid Capacitor design, Digi Power
• Supports Dual Channel DDR3/DDR3L 1600
• 1 PCIe 3.0 x16, 1 PCIe 2.0 x16
• Supports AMD Quad CrossFireX™ and CrossFireX™
• Graphics Output Options : DVI-D, D-Sub, HDMI
• Intel^® Gigabit LAN
• 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec)
• 4 SATA3, 2 SATA2, 4 USB 3.1 Gen1, 8 USB 2.0

BIOS & FIRMWARE: B85M PRO4

Open the .CAD file with OpenBoardView or Altium 365.

Open the PDF file whith Acrobat Reader

Legal Disclaimer

Manufacturer does not publicly release schematics or boardview files. These resources are shared to aid responsible repair efforts. Always comply with local laws and avoid unauthorized distribution. The information provided here is based on available specifications and features at the time of writing. Always check the official product documentation for the most up-to-date details. Use these schematics at your own risk.
